Part Number: MD6S







D/C: PF



Urgent Purchase

MD6S Maximum Ratings

RATINGS
SYMBOL
MD1S
MD2S
MD3S
MD4S
MD5S
MD6S
MD7S
UNITS
Maximum Recurrent Peak Reverse Voltage
VRRM
50
100
200
400
600
800
1000
Volts
Maximum RMS Bridge Input Voltage
VRMS
35
70
140
280
420
560
700
Volts
Maximum DC Blocking Voltage
VDC
50
100
200
400
600
800
1000
Volts
Maximum Average Forward Output Rectified
Current at TA = 30oC - on glass-epoxy P.C.B. ( NOTE 1 )
- on aluminum substrate ( NOTE 2 )
IO
0.5
0.8
Amps
Peak Forward Surge Current 8.3 ms single half sine-wave
superimposed on rated load (JEDEC method)
IFSM
30
Amps
Operating Temperature Range
TJ
-55 to + 150
0C
Storage Temperature Range
TSTG
-55 to + 150
0C

MD6S Features

·Surge overload rating - 30 amperes peak
·Ideal for printed circuit board
·Reliable low cost construction utilizing molded
·Glass passivated device
·Polarity symbols molded on body
·Mounting position: Any
·Weight: 0.5 gram
