MJE371

Configuration :
Maximum Operating Frequency :
Maximum Operating Temperature : + 150 C
Transistor Polarity : PNP
Mounting Style : Through Hole
Maximum DC Collector Current : 4 A
Collector- Emitter Voltage VCEO Max : 40 V
Packaging : Box
DC Collector/Base Gain hfe Min : 40
Package / Case : TO-126
Emitter- Base Voltage VEBO : - 4 V


Features:

• DC Current Gain - hFE = 40 (Min) @ IC = 1.0 Adc
• MJE371 is Complementary to NPN MJE521




Specifications

Rating	Symbol	Value	Unit
CollectorEmitter Voltage	VCEO	40	Vdc
CollectorBase Voltage	VCB	40	Vdc
EmitterBase Voltage	VEB	40	Vdc
Collector Current - Continuous - Peak	IC	4.0 8.0	Adc
Base Current - Continuous	IB	2.0	Adc
Total Power Dissipation @ TC = 25 Derate above 25	PD	40 320	Watts mW/
Operating and Storage Junction Temperature Range	TJ, Tstg	65 to +150

Description

MJE371 is designed for use in generalpurpose amplifier and switching circuits. Recommended for use in 5 to 20 Watt audio amplifiers utilizing complementary symmetry circuitry.
