Purchase MK1704A, In-stock MK1704A From SeekIC.
MFG:ICS Package Cooled:SOP8
Part Number: MK1704A
MFG: ICS
Package Cooled: SOP8
Description: The MK1704A is an upgraded version of the MK1704 and is recommended for all new designs.It off...
- Table of contents:
MK1704A
-
Suppliers
DataSheet
General Description
MK1704A General Description
The MK1704A is an upgraded version of the MK1704 and is recommended for all new designs.
It offers more reduction in the frequency amplitude peaks, and will support frequencies up to 140 MHz.
The MK1704A generates a low EMI output clock from a clock input. The part is designed to dither the LCD interface clock or other clocks for flat panel graphics controllers. The MK1704A uses ICS/MicroClock's proprietary mixture of analog and digital Phase-Locked Loop (PLL) technology to synthesize the frequency, and our patented technique to spread the frequency spectrum of the output, thereby reducing the frequency amplitude peaks by several dB.
We offer many other clocks for computers and computer peripherals. Consult us when you need to remove crystals and oscillators from your board.
MK1704A Maximum Ratings
| Parameter | Conditions | Minimum | Typical | Maximum | Units |
| ABSOLUTE MAXIMUM RATINGS (note 1) | |||||
| Supply Voltage, VDD | Referenced to GND | 7 | V | ||
| Inputs | Referenced to GND | -0.5 | VDD+.5V | V | |
| Clock Outputs | Referenced to GND | -0.5 | VDD+.5V | V | |
| Ambient Operating Temperature | 0 | 70 | |||
| Soldering Temperature | Max of 20 seconds | 260 | |||
| Storage temperature | -65 | 150 | |||
MK1704A Features
• Packaged in 8 pin SOIC
• Provides a spread spectrum output clock
• Supports leading flat panel controllers
• Accepts a clock input, provides same frequency dithered output
• Optimized for higher resolutions that require up to 140 MHz, as well as 40 MHz (SVGA) and 65 MHz (XVGA) clocks
• Peak reduction by 7dB - 14 dB typical on 3rd-19th odd harmonics
• Low EMI feature can be disabled
• 3.3 V or 5 V ±10% supply voltage
• Advanced, low power CMOS process
• See the MK1714-01 for a multiplier with low EMI which can operate from a crystal
• Provides a spread spectrum output clock
• Supports leading flat panel controllers
• Accepts a clock input, provides same frequency dithered output
• Optimized for higher resolutions that require up to 140 MHz, as well as 40 MHz (SVGA) and 65 MHz (XVGA) clocks
• Peak reduction by 7dB - 14 dB typical on 3rd-19th odd harmonics
• Low EMI feature can be disabled
• 3.3 V or 5 V ±10% supply voltage
• Advanced, low power CMOS process
• See the MK1714-01 for a multiplier with low EMI which can operate from a crystal
MK1704A Connection Diagram
MK1704A
