Series: -
PLL: Yes
Output: CMOS
Number of Circuits: 1
Ratio - Input:Output: 1:1
Differential - Input:Output: No/No
Mounting Type: Surface Mount
Input: Clock
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package: 8-SOIC
Operating Temperature: 0°C ~ 70°C
Type: Clock Generator
Frequency - Max: 140MHz
Voltage - Supply: 3 V ~ 5.5 V
Divider/Multiplier: No/Yes
Manufacturer: IDT, Integrated Device Technology Inc
Packaging: Tape & Reel (TR)
Specifications | Temperature | C |
| Voltage | 5.0 V |
| Package | SOIC 8 |
| Speed | NA |
DescriptionLOW EMI CLOCK GENERATOR
The MK1704A is an upgraded version of the MK1704 and is recommended for all new designs. MK1704ALFTR offers more reduction in the frequency amplitude peaks and will support frequencies up to 140 MHz. The MK1704A generates a low EMI output clock from aclock input. The part of MK1704ALFTR is designed to dither the LCD interface clock or other clocks for flat panel graphics controllers. The MK1704A uses IDT's proprietary mixture of analog and digital Phase Locked Loop (PLL) technology to synthesize the frequency. MK1704ALFTR also uses IDT's patented technique to spread the frequency spectrum of the output, thereby reducing the frequency amplitude peaks by several dB.
8 pin SOIC package
Available in Pb (lead) free package
Provides a spread spectrum output clock
Supports leading flat panel controllers
Accepts a clock input, provides same frequency dithered output
Optimized for higher resolutions that require up to 140 MHz, as well as 40 MHz (SVGA) and 65 MHz (XVGA) clocks
Peak reduction by 7 dB - 14 dB typical on 3rd - 19th odd harmonics
Low EMI feature can be disabled
Operating voltage of 3.3V or 5V
Advanced, low power CMOS process
See the MK1714-01 for a multiplier with low EMI which can operate from a crystalParameters: | Technical/Catalog Information | MK1704ALFTR |
| Vendor | IDT, Integrated Device Technology Inc |
| Category | Integrated Circuits (ICs) |
| Type | Clock Generator |
| Voltage - Supply | 3 V ~ 5.5 V |
| Number of Outputs | 1 |
| Input | Clock |
| Output | Clock |
| Frequency-Max | 140MHz |
| Package / Case | 8-SOIC |
| Packaging | Tape & Reel (TR) |
| Operating Temperature | 0°C ~ 70°C |
| Lead Free Status | Lead Free |
| RoHS Status | RoHS Compliant |
| Other Names | MK1704ALFTR
