Part Number: ML6102
Description: The ML6102 is a group of high-precision and low-power voltage detectors. The ML6102 consists of a high...
- Table of contents:
ML6102
-
Suppliers
DataSheet
General Description
ML6102 General Description
The ML6102 is a group of high-precision and low-power voltage detectors. The ML6102 consists of a highly-accurate and low-power reference voltage source, a comparator, a hysteresis circuit, and an output driver. Detect voltage is very accurate and stable with N-channel open drain and CMOS, are available. Output Voltage is in inverted sense compared with ML61 series voltage detector.
ML6102 Maximum Ratings
|
CHARACTERISTIC |
SYMBOL |
RATING |
UNIT | |
| Input Voltage |
VIN |
10 |
V | |
| Output Current |
IOUT |
50 |
mA | |
| Output Voltage |
VOUT |
VSS-0.3 ~VIN+0.3 |
V | |
| Continuous Total Power Dissipation |
SOT-23 |
Pd |
150 |
mW |
|
SOT-89 |
500 | |||
|
SO-92 |
300 | |||
| Operating Ambient Temperature |
TOPR |
-40 ~ +70 |
||
| Storage Temperature |
Tstg |
-40 ~ +70 |
||
ML6102 Features
· CMOS Low Power Consumption : Typical 1.0uA at Vin=2.0V
· Selectable Detect Voltage : 1.1V to 6.0V in 0.1V increments
· Highly Accurate : Detect Voltage 1.1V to 1.9V + 3% Detect Voltage 2.0V to 6.0V + 2%
· Operating Voltage : 0.8V to 10.0V
· Package Available : SOT23 (150mW), SOT89 (500mW) & TO92 (300mW)
· Selectable Detect Voltage : 1.1V to 6.0V in 0.1V increments
· Highly Accurate : Detect Voltage 1.1V to 1.9V + 3% Detect Voltage 2.0V to 6.0V + 2%
· Operating Voltage : 0.8V to 10.0V
· Package Available : SOT23 (150mW), SOT89 (500mW) & TO92 (300mW)
ML6102 Typical Application
·Memory Battery Back-up Circuits
·Power Failure Detection
·Power-on Reset Circuit
·System Battery Life and Charge Voltage Monitor
·Power Failure Detection
·Power-on Reset Circuit
·System Battery Life and Charge Voltage Monitor
