MMSZ5226B

Zener Diodes 3.3V 0.5W Zener

product image

MMSZ5226B Picture
See larger image
SeekIC No. : 00268509 Detail

MMSZ5226B: Zener Diodes 3.3V 0.5W Zener

MMSZ5226B Data Sheet

floor Price/Ceiling Price

US $ .04~.13 / Piece | Get Latest Price
Part Number:
MMSZ5226B
Mfg:
Fairchild Semiconductor
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~25
  • 25~100
  • 100~250
  • Unit Price
  • $.13
  • $.08
  • $.07
  • $.04
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2026/4/2

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Zener Voltage : 3.3 V Voltage Tolerance : 5 %
Zener Current : 20 mA Power Dissipation : 500 mW
Maximum Reverse Leakage Current : 25 uA Maximum Zener Impedance : 28 Ohms
Maximum Operating Temperature : + 150 C Mounting Style : SMD/SMT
Package / Case : SOD-123 Packaging : Reel

Description

Voltage Temperature Coefficient :
Voltage Tolerance : 5 %
Maximum Operating Temperature : + 150 C
Mounting Style : SMD/SMT
Packaging : Reel
Zener Current : 20 mA
Power Dissipation : 500 mW
Package / Case : SOD-123
Zener Voltage : 3.3 V
Maximum Reverse Leakage Current : 25 uA
Maximum Zener Impedance : 28 Ohms


Features:

• Compact surface mount with same footprint as mini-melf
• 500 mW rating on FR-4 or FR-5 board.
• Class 3 ESD rating (>16 kV) per Human Body Model




Specifications

Part Number MMSZ5226B
Power Rating (mW) 500
NomVZ 3.3
@ IZT (mA) 20
Tol V (typ) (%) 5
IR (µA) 25


Parameter
Value
Units
Storage Temperature
-55 to +150
°C
Maximum Junction Temperature
-55 to +150
mW
Total Power Dissipation at 25°C
Derate above 25°C
500
6.7
mW/°C
Thermal Resistance (RØJA) Junction to Ambient (note 2)
340
°C/W
Maximum Temperature Coefficient
-0.070
%/°C
Nominal Zener Voltage (VZ) at 20 mA
3.3
V





Description

Half watt, General purpose, Medium Current Surface Mount Zener in the SOD-123 package. The MMSZ5226B SOD-123 package has the same footprint as the glass mini-melf (LL-34) package & provides a convenient alternative to the Leadless package.






Parameters:

Technical/Catalog InformationMMSZ5226B
VendorFairchild Semiconductor
CategoryDiscrete Semiconductor Products
Voltage - Zener (Nom) (Vz)3.3V
Power - Max500mW
Impedance (Max) (Zzt)26 Ohm
Voltage - Forward (Vf) (Max) @ If900mV @ 10mA
Current - Reverse Leakage @ Vr25A @ 1V
Tolerance±5%
Mounting TypeSurface Mount
Package / CaseSOD-123
PackagingTape & Reel (TR)
Operating Temperature-55°C ~ 150°C
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names MMSZ5226B
MMSZ5226B
MMSZ5226BFS ND
MMSZ5226BFSND
MMSZ5226BFS
