MP1010
-
Suppliers
DataSheet
General Description
MP1010 Maximum Ratings
| Characteristic |
Symbol |
MP 1000 |
MP 1001 |
MP 1002 |
MP 1004 |
MP 1006 |
MP 1008 |
MP 1010 |
Unit |
| Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage |
VRRM VRWM VR |
50 | 100 | 200 | 400 | 600 | 800 | 1000 |
V |
| RMS Reverse Voltage |
VR(RMS) |
35 | 70 | 140 | 280 | 420 | 560 | 700 |
V |
| Average Rectified Output Current(Note 1) @TA = 50 |
IO |
10 |
A | ||||||
| Non-Repetitive Peak Forward Surge Current 8.3 mS single half sine-wave superimposed on rated load (JEDEC Method) |
IFSM |
100 |
A | ||||||
| Forward Voltage (per Element) @IF = 5.0A |
VFM |
1.1 |
V | ||||||
| Peak Reverse Current @TC = 25 At Rated DC Blocking Voltage @TC = 100 |
IR |
10 1.0 |
A mA | ||||||
| I2t Rating for Fusing (t<8.3ms) (Note 2) |
I2t |
64 |
A2s | ||||||
| Typical Junction Capacitance (Note 3) |
Cj |
110 |
pF | ||||||
| Typical Thermal Resistance (Note 4) |
RJC |
7.5 |
K/W | ||||||
| Operating and Storage Temperature Range |
Tj ,TSTG |
-65 to +125 |
|||||||
2. Non-repetitive, for t > 1ms and < 8.3ms.
3. Measured at 1.0 MHz and applied reverse voltage of 4.0V D.C.
4. Thermal resistance junction to case per element
MP1010 Features
· Diffused Junction
· High Current Capability
· High Case Dielectric Strength
· High Surge Current Capability
· Ideal for Printed Circuit Board Application
· Plastic Material has Underwriters Laboratory Flammability Classification 94V-O
· High Current Capability
· High Case Dielectric Strength
· High Surge Current Capability
· Ideal for Printed Circuit Board Application
· Plastic Material has Underwriters Laboratory Flammability Classification 94V-O
