General Description
MP1501 Maximum Ratings
| Characteristic | Symbol |
MP 1500 |
MP 1501 |
MP 1502 |
MP 1504 |
MP 1506 |
MP 1508 |
MP 1510 |
UNITS |
| Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage |
VRRM VRWM VR |
50 |
100 |
200 |
400 |
600 |
800 |
1000 |
V |
| RMS Reverse Voltage | VR(RMS) |
35 |
70 |
140 |
280 |
420 |
560 |
700 |
V |
| Average Rectified Output Current (Note 1) @TC = 70°C | IO |
15 |
A | ||||||
| Non-Repetitive Peak Forward Surge Current 8.3ms Single half sine-wave superimposed on rated load (JEDEC Method) |
IFSM |
300 |
A | ||||||
| Forward Voltage (per element) @IF = 7.5A | VFM |
1.1 |
V | ||||||
| Peak Reverse Current @TC = 25°C At Rated DC Blocking Voltage @TC = 100°C |
IR |
10 1.0 |
µA mA | ||||||
| I2t Rating for Fusing (t<8.3ms) (Note 2) | I2t |
64 |
A2s | ||||||
| Typical Junction Capacitance (Note 3) | Cj |
110 |
pF | ||||||
| Typical Thermal Resistance (Note 4) | RJC |
7.5 |
K/W | ||||||
| Operating and Storage Temperature Range | Tj, TSTG |
-65 to +125 |
°C | ||||||
2. Non-repetitive, for t > 1ms and < 8.3ms.
3. Measured at 1.0 MHz and applied reverse voltage of 4.0V D.C.
4. Thermal resistance junction to case per element.
MP1501 Features
·Diffused Junction
·High Current Capability
·High Case Dielectric Strength
·High Surge Current Capability
·Ideal for Printed Circuit Board Application
·Plastic Material has Underwriters Laboratory Flammability Classification 94V-O
·High Current Capability
·High Case Dielectric Strength
·High Surge Current Capability
·Ideal for Printed Circuit Board Application
·Plastic Material has Underwriters Laboratory Flammability Classification 94V-O
MP1501
PDF/DataSheet Download
- Datasheet: MP1501
- File Size: 43323 KB
- Manufacturer: WTE [Won-Top Electronics]
- Click here to Download
