Position: Home > Datasheet list > MSP Series > Index M > MSP430F5438IPZ
Electronica China

Purchase MSP430F5438IPZ, In-stock MSP430F5438IPZ From SeekIC.

MFG:Texas Instruments  Category:Integrated Circuits (ICs)

MSP430F5438IPZ

MSP Series Datasheet download

Five Points

Part Number: MSP430F5438IPZ

Category: Integrated Circuits (ICs)

MFG: Texas Instruments





Descriptions: IC MCU 16BIT 256K FLASH 100-LQFP

Price Break

1
25
100
250
500
1000
5000

Unit Price

9.70000
7.76000
6.54750
6.30500
6.15950
6.06250
5.91700

Extended Price

9.70
194.00
654.75
1576.25
3079.75
6062.50
29585.00

(All prices are in USD) Prices for reference only
Urgent Purchase

MSP430F5438IPZ General Description

IC MCU 16BIT 256K FLASH 100-LQFP

MSP430F5438IPZ Parameters

Technical/Catalog InformationMSP430F5438IPZ
VendorTexas Instruments
CategoryIntegrated Circuits (ICs)
Program Memory Size256KB (256K x 8 + 512B)
RAM Size16K x 8
Number of I /O87
Package / Case100-LQFP
Speed18MHz
Controller SeriesMSP430
Oscillator TypeExternal
PackagingTray
Program Memory TypeFLASH
EEPROM Size-
Core ProcessorRISC
Data ConvertersA/D 16x12b
Core Size16-Bit
Operating Temperature-40°C ~ 85°C
ConnectivityI²C, IrDA, SPI, UART/USART
PeripheralsBrown-out Detect/Reset, DMA, POR, PWM, WDT
Voltage - Supply (Vcc/Vdd)2.2 V ~ 3.6 V
Drawing Number*
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names MSP430F5438IPZ
MSP430F5438IPZ
296 23450 ND
29623450ND
296-23450

MSP430F5438IPZ datasheet

MSP01
PDF/DataSheet Download

Find MSP430F5438IPZ Suppliers
