MSS6132-682MLC

The MSS6132-682MLC is designed as one kind of 6.1 * 6.1 mm footprint; 3.2 mm high shielded inductors with some features and absolute maximum ratings:(1)designer's kit C364 contains 3 of each value;(2)core material ferrite;(3)core and winding loss see www.coilcraft.com/coreloss;(4)terminations RoHS compliant gold over nickel over phos bronze.other terminations available at additional cost.;(5)weight 0.33-0.38 g;(6)ambient temperature:-40°C to +85°C with Irms current,+85°C to +125°C with derated current;(7)storage temperature component:-40°C to +125°C,packaging:-40°C to +80°C;(8)resistance to soldering heat max three 40 second reflows at +260°C, parts cooled to room temperature between cycles;(9)moisture sensitivity level (MSL) 1 (unlimited floor life at <30°C /85% relative humidity);(10)failures in time (FIT) / mean time between failures (MTBF) 38 per billion hours / 26,315,789 hours, calculated per Telcordia SR-332;(11)packaging 500/7" reel,1500/13" reel; plastic tape:16 mm wide,0.3 mm thick,12 mm pocket spacing, 3.1 mm pocket depth;(12)PCB washing Only pure water or alcohol recommended.

Some points of the MSS6132-682MLC should be notice:(1)please specify termination and packaging codes;(2)inductance tested at 100 kHz, 0.1 Vrms, 0 Adc using an agilent/HP 4263B LCR meter or equivalent;(3)SRF measured using Agilent/HP 4191A or equilvalent;(4)DC current at which the inductance drops the specified amount from its value without current;(5)current that causes the specified temperature rise from 25°C ambient;(6)electrical specifications at 25°C.If you want to know more information such as the electrical characteristics about the MSS6132-682MLC,please download the datasheet in www.seekic.com or www.chinaicmart.com .
