Part Number: MUN2115RT1
Description: This new series of digital transistors is designed to replace a single device and its external resisto...
- Table of contents:
MUN2115RT1
-
Suppliers
DataSheet
General Description
MUN2115RT1 General Description
This new series of digital transistors is designed to replace a single device and its external resistor bias network. The BRT (Bias Resistor Transistor) contains a single transistor with a monolithic bias network consisting of two resistors; a series base resistor and a baseemitter resistor. The BRT eliminates these individual components by integrating them into a single device. The use of a BRT can reduce both system cost and board space. The device is housed in the SC59 package which is designed for low power surface mount applications.
MUN2115RT1 Maximum Ratings
| Rating |
Symbol |
Value |
Unit |
| Collector-Base Voltage |
VCBO |
50 |
Vdc |
| Collector-Emitter Voltage |
VCEO |
50 |
Vdc |
| Collector Current |
IC |
100 |
mAdc |
| Total Power Dissipation @ T A = 25°C (1) Derate above 25°C |
PD |
200 1.6 |
mW mW/°C |
MUN2115RT1 Features
• Simplifies Circuit Design
• Reduces Board Space
• Reduces Component Count
• The SC59 package can be soldered using wave or reflow. The modified gullwinged leads absorb thermal stress during soldering eliminating the possibility of damage to the die.
• Available in 8 mm embossed tape and reel Use the Device Number to order the 7 inch/3000 unit reel.
• Reduces Board Space
• Reduces Component Count
• The SC59 package can be soldered using wave or reflow. The modified gullwinged leads absorb thermal stress during soldering eliminating the possibility of damage to the die.
• Available in 8 mm embossed tape and reel Use the Device Number to order the 7 inch/3000 unit reel.
