N1000

The N1000 series is a range of system-orientated, one to four output power supplies which provide 1000W of continuous power at line voltages from 90VAC to 264VAC. Both N1000 series are harmonically corrected and carry world wide safety approvals. Fully enclosed, fan cooled and in the industry standard 5 x 8 x 11 inch form, the N series is an ideal choice when the economy and predictable performance of a centralized system power supply are desired. A unique dual converter architecture isolates the 5VDC logic output and the peripheral voltages.

The N1000 has the following features including:(1)active harmonic correction to EN61000-3-2; (2)90VAC to 264VAC universal input; (3)flexible output voltage configuration; (4)two output power ratings; (5)forced current sharing, all outputs; (6)DC OK (including LED); (7)UL, CSA and TUV safety approvals; (8)industry standard 5 x 8 x 11 inch footprint.Maximum flexibility is provided as power budgets shift and change during the design cycle or as system upgrades are implemented. This overcomes a major shortfall of many system power supplies which use a single converter. To meet redundancy requirements, each output rail is isolated, individually regulated and features forced current share.

The absolute maximum ratings of the N1000 are:(1)input voltage range:90 to 264V; (2)input frequency range:47Hz to 63Hz; (3)operating temperature:0 to 50.The information given herein, including the specifications and dimensions, is subject to change without prior notice to improve product characteristics. Before ordering, purchasers are advised to contact the Sensitron Semiconductor sales department for the latest version of the datasheet(s).In cases where extremely high reliability is required (such as use in nuclear power control, aerospace and aviation, traffic equipment,medical equipment, and safety equipment), safety should be ensured by using semiconductor devices that feature assured safety or by means of users' fail-safe precautions or other arrangement.In no event shall Sensitron Semiconductor be liable for any damages that may result from an accident or any other cause during operation of the user's units according to the datasheet(s). Sensitron Semiconductor assumes no responsibility for any intellectual property claims or any other problems that may result from applications of information, products or circuits described in the datasheets.
