MFG:ON Semiconductor Category:Discrete Semiconductor Products
Category: Discrete Semiconductor Products
MFG: ON Semiconductor
Descriptions: MOSFET P-CH 12V 3.4A 6-TSOP
| Technical/Catalog Information | NTGS3447PT1G |
| Vendor | ON Semiconductor |
| Category | Discrete Semiconductor Products |
| Mounting Type | Surface Mount |
| FET Polarity | P-Channel |
| Drain to Source Voltage (Vdss) | 12V |
| Current - Continuous Drain (Id) @ 25° C | 3.4A |
| Rds On (Max) @ Id, Vgs | 40 mOhm @ 4.7A, 4.5V |
| Input Capacitance (Ciss) @ Vds | 1053pF @ 6V |
| Power - Max | 700mW |
| Packaging | Tape & Reel (TR) |
| Gate Charge (Qg) @ Vgs | 15nC @ 4.5V |
| Package / Case | 6-TSOP |
| FET Feature | Logic Level Gate |
| Drawing Number | * |
| Lead Free Status | Lead Free |
| RoHS Status | RoHS Compliant |
| Other Names | NTGS3447PT1G NTGS3447PT1G |
