P171

Features:

` Low-profile, 4-lead mini-DIL package:
- Suitable for SONET applications
`Optional differential output in a 6-lead mini-DIL package
` Transimpedance amplifier with automatic gain control (AGC)
` Metal package:
- Offers superior shielding for high noise immunity
` High performance:
- High speed (<0.5 ns typical rise and fall time)
- High responsivity (0.85 A/W typical)
- Low dark current
`Planar structure for high reliability
` Wavelength: 1.1m-1.6m
`50m core multimode fiber
` Wide operating temperature range:
- 40 to +85
` Wide bandwidth
` Qualification program: Telcordia Technologies * TA-NWT-983
` Typical sensitivity:
- 38 dBm at 155 Mbits/s
- 33 dBm at 622 Mbits/s


Application

· Long-reach SONET OC-3/OC-12 and SDH STM-1/STM-4 telecommunications applications
· Secure digital data systems
· Line terminal equipment


Specifications

Parameter	Symbol	Min	Max	Unit
Operating Temperature Range	TA	40	85
Storage Temperature Range	Tstg	40	90
Forward Voltage	VF	-	0	V
Reverse Voltage*	VR	-	30	V
VCC	VCC	0	6	V
Photocurren	-	-	4	mA
Humidity	-	-	95	%

* The recommended reverse bias voltage is 5 V to 15 V.


Description

The P171-type mini-DIL PIN/preamp consists of a PIN coupled to a multimode fiber pigtail and a wideband linear preamplifier. The PIN incorporated is a rear-illuminated planar diode structure with a low-capacitance active area for maximum responsivity and speed.

P171  incorporates the new laser 2000 manufacturing process from the Optoelectronics Products unit of Agere Systems Inc. Laser 2000 is a low-cost platform that targets high-volume manufacturing and tight product distributions on all optical subassemblies. This platform incorporates an advanced optical design that is produced on highly automated production lines. The laser 2000 platform is qualified for central office and uncontrolled environments, and can be used for applications requiring high performance and low cost.
