P7101-5650-822JT

The P7101-5650-822JT is designed as one member of the P7101 family which comprises rugged moulded inductors covering six decades of E12 standard values. The coils are encapsulated in heat-proof thermoset resin providing resistance to shock, pressure, heat, humidity and solvents to MIL-STD-202F. As such, P7101-5650-822JT have wide application in consumer and industrial electronics. Components are available in three mechanical sizes similar to EIA 1210, 1812 and 2220 covering 10nH to 10mH. The P7101 family of components is compliant with RoHS Directive 2002/95/EC, and suitable for lead-free and conventional placement and reflow.

P7101-5650-822JT has nine features. (1)Encapsulated. (2)Lead-free (Pb-free). (3)Rugged. (4)RoHS compliant. (5)Industry standard. (6)Wide range (0.01 to 10000uH). (7)E12 inductance values. (8)Surface mount. (9)Flat top for pick & place. Those are all the main features.

Some absolute maximum ratings of P7101-5650-822JT have been concluded into several points as follow. (1)Its storage temperature range would be from -40°C to 125°C. (2)Its operating temperature range would be frm -40°C to 125°C. (3)Its soldering temperature profile peak would be 260°C 10s. It should be noted that stresses above those listed in absolute maximum ratings may cause permanent damage to device. Handle in accordance with IPC/JEDEC J-STD-033 procedure for components classified as IPC/JEDEC J-STD-020 moisture sensitivity level 2.

Also some electrical characteristics of P7101-5650-822JT are concluded as follow. (1)Its inductance would be 8200+/-5%uH. (2)Its Q would be min 30. (3)Its test frequency would be 0.25MHz. (4)Its SRF would be min 0.6MHz. (5)Its DCR would be max 125ohms. (6)Its rated current Idc would be 28mA. And so on. It should be noted that test frequency relates to measurement of inductance and Q. Rated current, IDC, is the current at which the zero-current inductance drops by 10% (max) or temperature rises by 20°C (max). If you have any question or suggestion or want to know more information about P7101-5650-822JT please contact us for details. Thank you!
