PC702V
-
Suppliers
DataSheet
General Description
PC702V Maximum Ratings
| Parameter | Symbol | Rating | Unit | |
| Input | *1Forward current | IF | 60 | mA |
| *1Peak forward current | IFM | 1.5 | A | |
| Reverse voltage | VR | 6 | V | |
| Power dissipation | P | 105 | mW | |
| Output | Collector-emitter voltage | VCEO | 70 | V |
| Emitter-collector voltage | VECO | 6 | V | |
| Collector-base voltage | VCBO | 70 | V | |
| Emitter-base voltage | V EBO | 6 | V | |
| Output current | IC | 50 | mA | |
| Collector power dissipation | PC | 160 | mW | |
| Total power dissipation | Ptot | 200 | mW | |
| *2Isolation voltage | Viso | 5000 | V rms | |
| Total power dissipation | Topr | - 55 to + 100 | °C | |
| Storage temperature | Tstg | - 55 to + 150 | °C | |
| *3Soldering temperature | Tsol | 260 | °C | |
*2 40 to 60% RH, AC for 1 minute
*3 For 10 seconds
PC702V Features
1. High collector-emitter voltage (VCEO : 70V)
2. High isolation voltage between input andoutput (Viso: 5 000V rms )
3. TTL compatible output
4. Recognized by UL, file No. E64380
2. High isolation voltage between input andoutput (Viso: 5 000V rms )
3. TTL compatible output
4. Recognized by UL, file No. E64380
PC702V Typical Application
1. Telephone sets, telephone exchangers
2. System appliances, measuring instruments
3. Signal transmission between circuits of different potentials and impedances
2. System appliances, measuring instruments
3. Signal transmission between circuits of different potentials and impedances
