Purchase PEB7274, In-stock PEB7274 From SeekIC.
MFG:SIEMENS Package Cooled:QFP44
- Table of contents:
PEB7274
-
Suppliers
DataSheet
General Description
PEB7274 Maximum Ratings
|
Parameter |
Symbol |
Limit Values |
Unit |
| Voltage on any pin with respect to ground |
VS |
0.3 to VDD+0.3 |
V |
| Maximum voltage on any pin |
Vmax |
7 |
V |
| Ambient temperature under bias PEB PEF |
TA TA |
0 to 70 40 to 85 |
|
| Storage temperature |
Tstg |
65 to 125 |
Note: Stresses above those listed here may cause permanent damage to the device.Exposure to absolute maximum rating conditions for extended periods may affect device reliability.
PEB7274 Features
• 4 full duplex ADPCM Voice Coders
• 16/24/32/40 kbit/s compression rate
• CCITT G.726, G.721 compliant
• Compression rate individually programmable during operation
• Cascadable for PCM-8 Systems
• Parameterizable Echosupression
• Programmable tone generation
• A-Law, -Law or 16 bit linear operation
• Pprogrammable FAX/Modem-tone detection,compliant to G.164
• Optional Artificial Echo Loss compliant to ETSI ETS 300 175
• Stand-alone operation in PCM-4 Systems without microcontroller
• A-law or -law default set per pin strapping
• 2 PCM-Interfaces 1.536, 2.048 or 4.096 MHz providing 12 to 64 time slots
• Frame Strobe Signals for standard codec filters, long frame and short frame timing
• Serial Microcontroller Interface
• DECT synchronization clock
• JTAG Boundary Scan compliant to IEEE 1149.1
• Sub-micron CMOS Technology
• P-MQFP-44 Package
• 16/24/32/40 kbit/s compression rate
• CCITT G.726, G.721 compliant
• Compression rate individually programmable during operation
• Cascadable for PCM-8 Systems
• Parameterizable Echosupression
• Programmable tone generation
• A-Law, -Law or 16 bit linear operation
• Pprogrammable FAX/Modem-tone detection,compliant to G.164
• Optional Artificial Echo Loss compliant to ETSI ETS 300 175
• Stand-alone operation in PCM-4 Systems without microcontroller
• A-law or -law default set per pin strapping
• 2 PCM-Interfaces 1.536, 2.048 or 4.096 MHz providing 12 to 64 time slots
• Frame Strobe Signals for standard codec filters, long frame and short frame timing
• Serial Microcontroller Interface
• DECT synchronization clock
• JTAG Boundary Scan compliant to IEEE 1149.1
• Sub-micron CMOS Technology
• P-MQFP-44 Package
PEB7274 Connection Diagram
