MFG:PERICOM Package Cooled:STK D/C:0611+
MFG: PERICOM
Package Cooled: STK
D/C: 0611+
Description: Pericom Semiconductor's PI3B16233 is a 16-bit to 32-bit mux/demux switch. This device can be used for ...
Pericom Semiconductor's PI3B16233 is a 16-bit to 32-bit mux/demux switch. This device can be used for memory bank interleaving. The PI3B16233 can be used as two 8-bit to 16-bit multiplexers or as one 16-bit to 32-bit multiplexer.
Two select inputs (SEL1 and SEL2) control the data flow. When the TEST inputs are asserted HIGH, the A port is connected to both the B1 and the B2 ports.
Above which the useful life may be impaired. For user guidelines, not tested.
Storage Temperature ...................................................... 65°C to +150°C
Ambient Temperature with Power Applied ...................... 40°C to +85°C
Supply Voltage Range ....................................................... 0.5V to +4.6V
DC Input Voltage ............................................................... 0.5V to +4.6V
DC Output Current ........................................................................ 120mA
Power Dissipation ............................................................................. 0.5W
Note: Stresses greater than those listed under MAXIMUM RATINGS may cause permanent damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect reliability.
• 5-ohm Switch Connection Between Two Ports
• Nea-Zero Propagation Delay
• Fast Switching Speed: 4.5ns (max.)
• Ultra -Low Quiescent Power (0.2mA typical) - ideal for notebook applications.
• Industrial Operating Temperature: 40ºC to 85ºC
• Package (Pb-free & Green available): - 56-pin 240-mil wide plastic TSSOP(A) - 56-pin 300- mil wide plastic SSOP (V)
PI3B16233
PDF/DataSheet Download
