MFG:PERICOM Package Cooled:STK D/C:0605+
MFG: PERICOM
Package Cooled: STK
D/C: 0605+
Description: Pericom Semiconductor's PI3B series of logic circuits are producedusing the Company's advanced 0.35 mi...
Pericom Semiconductor's PI3B series of logic circuits are producedusing the Company's advanced 0.35 micron CMOS technology.
The PI3B16245 and PI3B162245 are 3.3 volt, hot-insertion, 16-bit,2-port bus switches that are pin compatible with the 74 series 1624516-bit transceiver. Two enable signals (nBE) turn the switches onimilar to the enable signals of the 16245. The bus switches createno additional propagational delay or additional ground bouncenoise.
The PI3B162245 device has a built-in 25-ohm series resistor toreduce noise resulting from reflections, thus eliminating the need or an external terminating resistor.
Above which the useful life may be impaired. For user guidelines, not tested.
Storage Temperature ....................................................... 65°C to +150°C
Ambient Temperature with Power Applied ........................ 0°C to +85°C
Supply Voltage Range ........................................................ 0.5V to +4.6V
DC Input Voltage ............................................................... 0.5V to +4.6V
DC Output Current ......................................................................... 120 mA
Power Dissipation ............................................................................... 0.5W
Note:
Stresses greater than those listed under MAXIMUMRATINGS may cause permanent damage to the device.This is a stress rating only and functional operation of thedevice at these or any other conditions above those indicatedin the operational sections of this specification is notimplied. Exposure to absolute maximum rating conditionsfor extended periods may affect reliability.
PI3B16245
