PI3C16226

Above which the useful life may be impaired. For user guidelines, not tested.

Storage Temperature .......................................................... –65°C to +150°C
Ambient Temperature with Power Applied ............................ –40°C to +85°C
Supply Voltage to Ground Potential (Inputs & Vcc Only) ...... –0.5V to +4.6V
Supply Voltage to Ground Potential (Outputs & D/O Only) ... –0.5V to +4.6V
DC I/O Voltage ........................................................................ –0.5V to +5.5V
DC Output Current .............................................................................. 120mA
Power Dissipation ................................................................................... 0.5W

Note: Stresses greater than those listed under MAXIMUM RATINGS may cause permanent damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect reliability.

Pericom Semiconductor's PI3C series of bus switch circuits are produced using the Company's advanced submicron CMOS technology, achieving industry leading performance.

in the PI3C series , PI3C16226 is a 12-to 24-bit multiplexer/demultiplexer bus switch.Industry leading advantages include a zero propagation delay of 500ps, resulting from 9-ohm channel resistance and low I/O capacitance. A1 port demultiplexes to either 1B or 2B and the switch is bidirectional.
