PI3C16234

Above which the useful life may be impaired. For user guidelines, not tested.

Storage Temperature ....................................................... –65°C to +150°C
Ambient Temperature with Power Applied ....................... –40°C to +85°C
Supply Voltage Range ....................................................... –0.5V to +4.6V
DC I/O Voltage ................................................................... –0.5V to +5.5V
DC Output Current ......................................................................... 120mA
Power Dissipation ............................................................................. 0.5W

Note: Stresses greater than those listed under MAXIMUM RATINGS may cause permanent damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect reliability.

Pericom Semiconductor's PI3C series of logic circuits are produced using the Company's advanced submicron CMOS technology.

In the  PI3C series , the PI3C16234 is a 16-bit to 32-bit mux/demux switch. Industry leading advantages include almost zero propagation delay of 500ps because of the 9ohm channel resistance and low I/O capacitance. A1 port demultiplexes to either port B1 or B2 and the switch is bidirectional.
