PI5C16211

Above which the useful life may be impaired. For user guidelines, not tested.

Storage Temperature .................................................................... 65°C to +150°C
Ambient Temperature with Power Applied .................................... 40°C to +85°C
Supply Voltage to Ground Potential (Inputs & Vcc Only) .............. 0.5V to +7.0V
Supply Voltage to Ground Potential (Outputs & D/O Only) ........... 0.5V to +7.0V
DC Input Voltage ............................................................................ 0.5V to +7.0V
DC Output Current ...................................................................................... 120mA
Power Dissipation ..........................................................................................1.4W

Note: Stresses greater than those listed under MAXIMUM RATINGS may cause permanent damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect reliability.

Pericom Semiconductor's PI5C series of logic circuits are produced using the Company's advanced 0.6 micron CMOS technology. The PI5C16211 is a 24-bit bus switch designed with a low ON resistance allowing inputs to be connected directly to outputs. PI5C16211 operates as a 24-bit or a 12-bit bus switch, which provides high speed bus switching.
