PM3604-10-RC

Common Mode Inductors (Chokes) 10uH 20%

product image

PM3604-10-RC Picture
See larger image
SeekIC No. : 001170320 Detail

PM3604-10-RC: Common Mode Inductors (Chokes) 10uH 20%

PM3604-10-RC Data Sheet

floor Price/Ceiling Price

US $ .55~1.06 / Piece | Get Latest Price
Part Number:
PM3604-10-RC
Mfg:
J.W. Miller
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~50
  • 50~100
  • 100~400
  • Unit Price
  • $1.06
  • $.58
  • $.56
  • $.55
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/5

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Inductance : 10 uH Tolerance : 20 %
Maximum DC Current : 1.83 Amps Maximum DC Resistance : 0.028 Ohms
Operating Temperature Range : - 55 C to + 125 C Termination Style : SMD/SMT
Package / Case : 3602

Description

Impedance :
Self Resonant Frequency :
Q Minimum :
Series :
Termination Style : SMD/SMT
Operating Temperature Range : - 55 C to + 125 C
Tolerance : 20 %
Inductance : 10 uH
Package / Case : 3602
Maximum DC Current : 1.83 Amps
Maximum DC Resistance : 0.028 Ohms


Parameters:

Technical/Catalog InformationPM3604-10-RC
VendorJW Miller A Bourns Company
CategoryInductors, Coils, Chokes
DC Resistance (DCR)55.00 mOhm Max
Current 1.35A
Number of Coils2
Mounting TypeSurface Mount
Package / Case0.550" L x 0.452" W x 0.265" H (13.97mm x 11.48mm x 6.73mm)
Tolerance±20%
PackagingTape & Reel (TR)
Inductance Per Coil20H
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names PM3604 10 RC
PM360410RC
M10150TR ND
M10150TRND
M10150TR
