Product Details

Description



Features:

· Flexibility to select between ordinary microprocessor control or enhanced with system reference clock features.
· Direct SCI-PHY to multi-PHY connection.


Application

· Interconnect 2 SCI-PHY EVMB with dual multi-PHY ATM daughter board.


Description

The Multi-PHY Adapter Card (MAC) facilitates the connection of two SCI-PHY EVMBs and a SWAN card to an ATM daughter card with two multi-PHY interfaces. Also, the MAC distributes power and microprocessor control to the SCI-PHY EVMBs, SWAN card and the multi-PHY interfaces.

The microprocessor PMC-970438 access to the Multi-PHY-X and Multi-PHY-Y interfaces is multiplexed between the SWAN, SCI-PHY EVMB #1 or SCI-PHY EVMB #2 microprocessor. Selection between these microprocessor interfaces is made with jumpers.

The Multi-PHY-X Interface connects directly to the SCI-PHY #1 multi-PHY interface and the Multi-PHY-Y Interface connects directly to the SCI-PHY #2 multi-PHY interface

The Power Connection block of PMC-970438 allows connection to an external power supply and includes over-current protection. Therefore, power connections to the other MAC peripheral boards are not required.
