PQ070XZ1HZ
-
Suppliers
DataSheet
General Description
PQ070XZ1HZ Maximum Ratings
| Parameter | Symbol | Rating | Unit | |
| Input voltage | VIN | 10 | V | |
| ON/OFF control terminal voltage | VC | 10 | V | |
| Output adjustment terminal voltage | VADJ | 5 | V | |
| Output current |
PQ070XZ5MZxH | IO | 0.5 | A |
| PQ070XZ01ZxH | 1 | A | ||
| Power dissipation | PD | 8 | w | |
| Junction temperature | Tj | 150 | °C | |
| Operating temperature | Topr | -40 to +85 | °C | |
| Storage temperature | Tstg | -40 to +150 | °C | |
| Soldering temperature | Tsol | 260(10s) | °C | |
❇2 PD:With infinite heat sink
❇3 Overheat protection may operate at Tj=125°C to 150°C
PQ070XZ1HZ Features
` Low voltage operation (Minimum operating voltage: 2.35V)
` Low dissipation current
Dissipation current at no load: MAX.2mA
Output OFF-state dissipation current: MAX.5A
` Low power-loss (Dropout voltage: MAX.0.5V)
` Built-in overcurrent and overheat protection functions
` Low dissipation current
Dissipation current at no load: MAX.2mA
Output OFF-state dissipation current: MAX.5A
` Low power-loss (Dropout voltage: MAX.0.5V)
` Built-in overcurrent and overheat protection functions
PQ070XZ1HZ Typical Application
· Power supplies for personal computers and peripheral equipment
· Power supplies for various electronic equipment such as
DVD player or STB
· Power supplies for various electronic equipment such as
DVD player or STB
PQ070XZ1HZ
PDF/DataSheet Download
- Datasheet: PQ070XZ1HZ
- File Size: 91932 KB
- Manufacturer: SHARP [Sharp Electrionic Components]
- Click here to Download
