General Description
PQ09RF1 Maximum Ratings
| Parameter | Symbol | Rating | Unit | |
| *1Input voltage |
VIN | 35 | V | |
| *1ON/OFF control terminal voltage |
PQ05RF1 series | VC | 35 | V |
| PQ05RF11 series | ||||
| Output current | IO | 1 | A | |
| Power dissipation (No heat sink) | PD1 | 1.5 | W | |
| Power dissipation (With infinite heat sink) | PD2 | 15 | W | |
| *2Junction temperature |
Tj | 150 | ||
| Operating temperature | Topr | -20 to +80 | ||
| Storage temperature | Tstg | -40 to +150 | ||
| Soldering temperature | Tsol | 260 (For 10s) | ||
*2 Overheat protection may operate at 125<=Tj<=150°C
PQ09RF1 Features
·Compact resin full-mold package
·Low power-loss (Dropout voltage:MAX.0.5V)
·Built-in ON/OFF control terminal (PQ05RF1/PQ05RF11 series)
·Built-in output voltage minute adjustment terminal (Critical rate of ripple rejection is improved.) (PQ05RF1V series)
·Lead forming type (PQ05RF1A/1B series) is also available.
·Low power-loss (Dropout voltage:MAX.0.5V)
·Built-in ON/OFF control terminal (PQ05RF1/PQ05RF11 series)
·Built-in output voltage minute adjustment terminal (Critical rate of ripple rejection is improved.) (PQ05RF1V series)
·Lead forming type (PQ05RF1A/1B series) is also available.
PQ09RF1 Typical Application
·Seris power supply for various electronic equipment such as VCRs and musical instruments
