PQ1CX12H2ZPQ

PQ1 Series Datasheet download

Five Points

Part Number: PQ1CX12H2ZPQ

Category: Integrated Circuits (ICs)

MFG: Sharp Microelectronics





Descriptions: IC REG CHOPPER .9W 2.5A 8-SOP

Price Break

1000

Unit Price

1.37750

Extended Price

1377.50

(All prices are in USD) Prices for reference only
Urgent Purchase

PQ1CX12H2ZPQ General Description

IC REG CHOPPER .9W 2.5A 8-SOP

PQ1CX12H2ZPQ Parameters

Technical/Catalog InformationPQ1CX12H2ZPQ
VendorSharp Microelectronics
CategoryIntegrated Circuits (ICs)
TypeStep-Down (Buck)
Number of Outputs1
Voltage - Input5 ~ 20 V
Voltage - Output1.26 ~ 24 V
Current - Output2.5A
Power - Output900mW
Package / Case8-SOP
PackagingTube
Internal Switch(s)Yes
SynchronousNo
Rds (On)-
Operating Temperature-30°C ~ 85°C
Frequency - Switching150kHz
Drawing Number*
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names PQ1CX12H2ZPQ
PQ1CX12H2ZPQ
