Features:

5W DIP Package
Regulated Output
Continuous Short Circuit Protection Auto-Restarting
Wide Input 2:1 & 4:1
UL94V-0 Package Material
Cost Effective
100% Burned In
Efficiency to 86%


Specifications

Input Voltage Range
2:1 & 4:1
Output Voltage Accuracy
±2% max.
Line Regulation (HL-LL)
±0.3% max.
Load Regulation (for output load current change from 20% to 100%)
±0.6% max.
Output Ripple and Noise (0,1µF capacitor on output, 20MHz BW)
50mVp-p max.
Operating Frequency at Full Load              2:1 input
(at nominal input voltage)                     4:1 input
120kHz typ.
200kHz typ.
Input Filter
Pi Network
Efficiency at Full Load
see above
Isolation Voltage SMD Pinout and metal case (see note1) (tested for 1 second)
Rated Working Voltage                 (long term isolation)
1.000VDC min.
see Application Notes
Isolation Voltage H1 types            (tested for 1 second)
Rated Working Voltage                 (long term isolation)
1.000VDC min.
see Application Notes
Isolation Capacitance
60pF typ.
Isolation Resistance
1 GΩ min.
Short Circuit Protection
Continuous, Auto Restart
Operating Temperature (free air convection)
-25°C to +75°C (see Graph)
Storage Temperature Range
-55°C to +125°C
Relative Humidity                             MSL Level 1
95% RH
Case Material
Non-Conductive Plastic
Thermal Impedance                    Natural convection
20°C/W for metal case
Package Weight
13 g
