RMB3S

Features: ` Ideal for printed circuit board` Reliable low cost construction utilizing molded plastic technique` High surge current capability` High temperature soldering guaranteed:260 / 10 seconds at 5 lbs., (2.3 kg) tension` Small size, simple installation` Pure tin plated terminal, Lead free.L...

product image

RMB3S Picture
See larger image
SeekIC No. : 004477957 Detail

RMB3S: Features: ` Ideal for printed circuit board` Reliable low cost construction utilizing molded plastic technique` High surge current capability` High temperature soldering guaranteed:260 / 10 seconds...

RMB3S Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
RMB3S
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/26

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

` Ideal for printed circuit board
` Reliable low cost construction utilizing molded plastic technique
` High surge current capability
` High temperature soldering guaranteed:260   / 10 seconds at 5 lbs., (2.3 kg) tension
` Small size, simple installation
` Pure tin plated terminal, Lead free.Leads solderable per MIL-STD-202 Method 208


Specifications

Parameter
Symbol
RMB2S
RMB4S
RMB6S
Unit
Maximum Recurrent Peak Reverse Voltage
VRRM
200
400
600
V
Maximum RMS Voltage
VRMS
140
280
420
V
Maximum DC Blocking Voltage
VDC
200
400
600
V
Maximum Average Forward Rectified Current
On glass-epoxy P.C.B.
On aluminum substrate
I(AV)
0.5
0.8
A
Peak Forward Surge Current, 8.3 ms Single
Half Sine-wave Superimposed on Rated Load
(JEDEC method )
IFSM
30
A
Maximum Instantaneous Forward Voltage @0.4A
VF
1.0
V
Maximum DC Reverse Current @ TA=25
at Rated DC Blocking Voltage @ TA=125
IR
5.0
100
uA
uA
Maximum Reverse Recovery Time at (Note 1)
Trr
150
ns
Typical Junction Capacitance Per Leg
Cj
13
pF
Typical Thermal Resistance Per Leg
RJA
85
°C/W
Operating Temperature Range
Tj
-55 to +150
°C
Storage Temperature Range
Tstg
-55 to +150
°C
Note: Reverse Recovery Test Conditions: IF=0.5A, IR=1.0A, IRR=0.25A
