Purchase RSR020P03TL, In-stock RSR020P03TL From SeekIC.

MFG:Rohm Semiconductor(VA)  Category:Discrete Semiconductor Products

RSR020P03TL

RSR Series Datasheet download

Five Points

Part Number: RSR020P03TL

Category: Discrete Semiconductor Products

MFG: Rohm Semiconductor(VA)





Descriptions: MOSFET P-CH 30V 2A TSMT3

Price Break

1
25
100
500
1000

Unit Price

.62000
.49200
.36900
.23370
.19680

Extended Price

0.62
12.30
36.90
116.85
196.80

(All prices are in USD) Prices for reference only
Urgent Purchase

RSR020P03TL General Description

MOSFET P-CH 30V 2A TSMT3

RSR020P03TL Parameters

Technical/Catalog InformationRSR020P03TL
VendorRohm Semiconductor(VA)
CategoryDiscrete Semiconductor Products
Mounting TypeSurface Mount
FET PolarityP-Channel
Drain to Source Voltage (Vdss)30V
Current - Continuous Drain (Id) @ 25° C2A
Rds On (Max) @ Id, Vgs120 mOhm @ 2A, 10V
Input Capacitance (Ciss) @ Vds 370pF @ 10V
Power - Max1W
PackagingCut Tape (CT)
Gate Charge (Qg) @ Vgs4.3nC @ 5V
Package / CaseTSMT3
FET FeatureLogic Level Gate
Drawing Number*
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names RSR020P03TL
RSR020P03TL
RSR020P03TLCT ND
RSR020P03TLCTND
RSR020P03TLCT
