RTC-58321/58323

Features: ·Adjustment-free built-in quartz resonator keeps component count low.· Built-in clock and calendar registers for year, month, day, day-of-week, hours, minutes and seconds.· 12-hour/24-hour selection.·Automatic leap-year correction, with software selection for local calendars.·Counter sta...

product image

RTC-58321/58323 Picture
See larger image
SeekIC No. : 004480070 Detail

RTC-58321/58323: Features: ·Adjustment-free built-in quartz resonator keeps component count low.· Built-in clock and calendar registers for year, month, day, day-of-week, hours, minutes and seconds.· 12-hour/24-hour...

RTC-58321/58323 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
RTC-58321/58323
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/26

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

·Adjustment-free built-in quartz resonator keeps component count low.
· Built-in clock and calendar registers for year, month, day, day-of-week, hours, minutes and seconds.
· 12-hour/24-hour selection.
·Automatic leap-year correction, with software selection for local calendars.
·Counter start, stop and reset functions.
· Periodic reference signal output selectable: 1024 Hz, or 1 second, 1 minute or 1 hour intervals.
·Data bus is 4-bit bidirectional, with memory-type reads and writes.
·CMOS device, for very low power consumption, and long battery back-up period.
·Compatible at pin and function levels with the MSM58321 RS.


Pinout

Connection Diagram Connection Diagram


Specifications

Item Symbol Condition(Pins) Rated Value Unit
Power supply voltage VDD Ta = 25°C, VDD-VSS -0.3 to +7.0 V
Input voltages VI Ta = 25°C input pins -0.3 to VDD +0.3 V
Output voltages VO D0 to D3 -0.3 to VDD +0.3 V
Storage temperature TSTG Temperature stored as
separate item.		 RTC-58321 -55 to +85 °C
RTC-58323 -55 to +125 °C
Soldering temperature TSOL RTC-58321 Maximum 260°C for up to 10 seconds (pins);
package maximum 150°C.
RTC-58323 Maximum 260°C for up to 10 seconds (twice maximum), or
maximum 230°C for up to three minutes.
