S116S01

RELAY SSR 120VAC 16A TRIAC 4-SIP

product image

S116S01 Picture
See larger image
SeekIC No. : 003832112 Detail

S116S01: RELAY SSR 120VAC 16A TRIAC 4-SIP

S116S01 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
S116S01
Mfg:
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/26

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Series: S116 Manufacturer: Sharp Microelectronics
Circuit: SPST-NO (1 Form A) Output Type: AC
On-State Resistance: - Load Current: 16A
Voltage - Input: 1.2VDC Voltage - Load: 0 ~ 120 V
Mounting Type: Through Hole Termination Style: PC Pin
Package / Case : PQFP-64 Package / Case: 4-SIP
Supplier Device Package: 4-SIP Packaging: Tube

Description

Circuit: SPST-NO (1 Form A)
Relay Type: Relay
Packaging: Tube
Mounting Type: Through Hole
Termination Style: PC Pin
On-State Resistance: -
Voltage - Input: 1.2VDC
Output Type: AC
Supplier Device Package: 4-SIP
Package / Case: 4-SIP
Manufacturer: Sharp Microelectronics
Voltage - Load: 0 ~ 120 V
Series: S116
Load Current: 16A


Features:

1. Compact, high radiation resin
mold package
2. RMS ON-state current
S112S01 Series: 12Arms at TC <= 70°C ( With heat sink)
S116S01 Series: 16Arms at TC <= 60°C ( With heat sink)
3. Built-in zero-cross circuit(S112S02 / S212S02 / S116S02 / S216S02 )
4. High repetitive peak OFF-state voltageS112S01/ S112S02 / S116S01 / S116S02
VDRM : 400VS212S01 / S212S02 / S216S01 / S216S02
VDRM : 600V
5. Isolation voltage between input and output
6. Recognized by UL, file No. E94758
7. Approved by CSA, No. 63705


Specifications

Parameter Symbol Rating Unit
Input Forward current IF 50 mA
Reverse voltage VR 6 V
Output RMS ON-state current S112S01 Series IT *412 Arms
S116S01 Series *516
*1Peak one cycle
surge current		 S112S01 Series I surge 120 A
S116S01 Series 160
Repetitive peak
OFF-state voltage		 S112S01 / S112S02
S116S01 / S116S02		 VDRM 400 V
S112S01 / S112S02
S116S01 / S116S02		 600
Non-repetitive peak
OFF-state voltage		 S112S01 / S112S02
S116S01 / S116S02		 VDSM 400 V
S112S01 / S112S02
S116S01 / S116S02		 600
Critical rate of rise of ON-state current dI/dt 50 A/m s
Operating frequency f 45 to 65 Hz
*2 Isolation voltage Viso 4000 Vrms
Operating temperature Topr - 25 to + 100
Storage temperature Tstg - 30 to + 125
*3Soldering temperature Tsol 260
