SAA5355

· Minimal additional hardware required
· Screen formats of 40/80 character by 1-to-25 row display
· 512 alphanumeric or graphical characters on-chip or extendable off-chip
· Serial attribute storage (STACK) and parallel attribute storage
· Dynamically redefinable character (DRCS) capability over full field
· Interfaces with 8/16-bit microprocessors with optional direct memory access
· On-chip scroll map minimizes data to be transferred when scrolling
· 32 on-screen colours redefinable from a palette of 4096
· Three on-chip digital-to-analogue converters which compensate for crt non-linearity
· Memory interface capable of supporting multi-page terminals. FTFROM can access up to 128 Kbytes of display memory
· Programmable cursor
· Programmable local status row
· Three synchronization modes:
    stand-alone              built-in oscillator operating with an external 6,041957 MHz crystal
    simple slave              directly synchronized from the source of text composite sync
    phase-locked slave   indirect synchronization allows picture-in-text displays (e.g. VCR/VLP video with text overlay)
· On-chip timing with composite sync output
· Zoom feature which allows the height of any group of rows to be increased to enhance legibility

The SAA5355 FTFROM (Five-Two-Five-ROM) is a single-chip VLSI NMOS crt controller capable of handling the display functions required for a 525-line, level-3 videotex decoder. Only minimal hardware SAA5355 is required to produce a videotex terminal using FTFROM - the simplest configuration needs just a microcontroller and 4 Kbytes of display memory.
