Part Number: SAA5361
Description: The SAA5360; SAA5361 is a single-chip multi page 625 line world system teletext decoder with a high-le...
- Table of contents:
SAA5361
-
Suppliers
DataSheet
General Description
SAA5361 General Description
The SAA5360; SAA5361 is a single-chip multi page 625 line world system teletext decoder with a high-level command interface, and is SAFARI compatible. The device is designed to minimize the overall system cost, due to the high-level command interface offering the benefit of a low software overhead in the TV microcontroller.
The SAA5360 incorporates the following functions:
· 10 page teletext decoder with OSD, fastext, TOP, default and list acquisition modes
· Automatic channel installation support.
The functionality of the SAA5361 is similar to the SAA5360, but offers the capability to store up to 250 additional pages of teletext in an external SRAM.
SAA5361 Maximum Ratings
| SYMBOL | PARAMETER | CONDITIONS | MIN. | MAX. | UNIT |
| VDD | all supply voltages | -0.5 | +4.0 | V | |
| VI | input voltage (any input) | VDD < 3.6 V; note 1 | -0.5 | VDD + 0.5 | V |
| VDD 3.6 V; note 1 | -0.5 | 4.1 | V | ||
| VO IO IIO(d) Tamb Tj Tstg |
output voltage (any output) output current (each output) diode DC input or output current ambient temperature junction temperature storage temperature |
note 1 |
-0.5 - - -20 -20 -55 |
VDD + 0.5 10 20 +70 +125 +125 |
V mA mA °C °C °C |
| Vesd | electrostatic discharge voltage | Human body model; C = 100 pF; R = 1.5 k |
- | 2000 | V |
| Machine model; C = 200 pF; R = 0 |
- | 200 | V | ||
| Ilu | latch-up current | 1.5 * VDD | - | 100 | mA |
1. This maximum value refers to 5 V tolerant I/Os and may be 6 V maximum but only when VDD is present.
SAA5361 Features
· Support for 50 or 60 and 100 or 120 Hz and progressive scan display modes
· Complete 625 line teletext decoder in one chip reduces printed-circuit board area and cost
· Automatic detection of transmitted fastext links or service information (packet 8/30)
· On-Screen Display (OSD) for user interface menus using teletext and dedicated menu icons
· Video Programming System (VPS) decoding
· Wide Screen Signalling (WSS) decoding
· SAA5360 supports Pan-European, Arabic and Iranian character sets
· SAA5361 supports Pan-European, Cyrillic, Greek and Arabic character sets
· High-level command interface via I2C-bus gives easy control with a low software overhead
· High-level command interface is backward compatible to Stand-Alone Fastext And Remote Interface (SAFARI)
· 625 and 525 line display
· RGB interface to standard colour decoder ICs; current source
· Versatile 8-bit open-drain Input/Output (I/O) expander; 5 V tolerant
· Single 12 MHz crystal oscillator
· Single power supply: from 3.0 V to 3.6 V
· Operating temperature: -20 to +70 °C
· Automatic detection of transmitted pages to be selected by page up and page down
· 8 page fastext decoder
· Table Of Pages (TOP) decoder with Basic Top Table (BTT) and Additional Information Tables (AITs)
· 4 page user-defined list mode.
· Complete 625 line teletext decoder in one chip reduces printed-circuit board area and cost
· Automatic detection of transmitted fastext links or service information (packet 8/30)
· On-Screen Display (OSD) for user interface menus using teletext and dedicated menu icons
· Video Programming System (VPS) decoding
· Wide Screen Signalling (WSS) decoding
· SAA5360 supports Pan-European, Arabic and Iranian character sets
· SAA5361 supports Pan-European, Cyrillic, Greek and Arabic character sets
· High-level command interface via I2C-bus gives easy control with a low software overhead
· High-level command interface is backward compatible to Stand-Alone Fastext And Remote Interface (SAFARI)
· 625 and 525 line display
· RGB interface to standard colour decoder ICs; current source
· Versatile 8-bit open-drain Input/Output (I/O) expander; 5 V tolerant
· Single 12 MHz crystal oscillator
· Single power supply: from 3.0 V to 3.6 V
· Operating temperature: -20 to +70 °C
· Automatic detection of transmitted pages to be selected by page up and page down
· 8 page fastext decoder
· Table Of Pages (TOP) decoder with Basic Top Table (BTT) and Additional Information Tables (AITs)
· 4 page user-defined list mode.
SAA5361 Connection Diagram
SAA5361
