SCD16

Features: *Plastic package has Underwriters Laboratory FlammabilityClassification 94V-0*For surface mounted applications*Low profile package*Built-in strain relief*Metal to silicon rectifier , majority carrier conduction*Low power loss , High efficiency*High current capability , low VF*High surge ...

product image

SCD16 Picture
See larger image
SeekIC No. : 004485904 Detail

SCD16: Features: *Plastic package has Underwriters Laboratory FlammabilityClassification 94V-0*For surface mounted applications*Low profile package*Built-in strain relief*Metal to silicon rectifier , major...

SCD16 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
SCD16
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/27

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

*Plastic package has Underwriters Laboratory FlammabilityClassification 94V-0
*For surface mounted applications
*Low profile package
*Built-in strain relief
*Metal to silicon rectifier , majority carrier conduction
*Low power loss , High efficiency
*High current capability , low VF
*High surge capacity
*For using in low voltage high frequency switching power supplyinverters , free wheeling , and polarity protection applications


Specifications

Ratings at 25 ambient temperature unless otherwise specified.
SYMBOLS
SCD12
SCD13
SCD14
SCD15
SCD316
UNITS
Maximum repetitive peak reverse voltage
V RRM
20
 30
40
50
60
Volts
Maximum RMS Voltage
V RMS
14
 21
28
35
42
Volts
Maximum DC Blocking Voltage
V DC
20
 30
40
50
60
Volts


Maximum average forward rectified current @TC = 75
I (AV)
1.0
Amps
Peak Forward Surge Current 8.3ms single half sine-wave superimposed on rated load(JEDEC method)
I FSM
30
Amps


Maximum instantaneous forward voltage   at 1.0 A (NOTE 1)

V F
0.50
0.70
Volts

Maximum DC Reverse Current      (Note 1)      @ TA=25
at Rated DC Blocking Voltage              @TA=100

I R
0.5
mA

10
5
Typical Junction capacitance ( NOTE 2 )
RJA
RJL
88
28

/W

Operating junction temperature range
TJ
-55 to +125
-55 to +150
Storage temperature range
TSTG
-55 to +150
