Product Details

Description



Features:

* High current capability
* High surge current capability
* High reliability
* Low reverse current
* Low forward voltage drop
* Super fast recovery time




Specifications

Rating at 25 °C ambient temperature unless otherwise specified.Single phase, half wave, 60 Hz, resistive or inductive load.For capacitive load, derate current by 20%.

TYPE NUMBER
SYMBOL
SF21
SF22
SF23
SF24
SF25
SF26
SF27
 SF28 SF29
UNITS
Maximum Recurrent Peak Reverse Voltage
VRRM
50
100
150
200
300
400
600
800
1000
V
Maximum RMS Voltage
VRMS
35
70
105
140
210
280
420
560
700
V
Maximum DC Blocking Voltage
VDC
50
100
150
200
300
400
600
800
1000
V
Maximum Average Forward Rectified Current
.375"(9.5mm) Lead Length at Tc=55
IF(AV)
2.0
A
Peak Forward Surge Current, 8.3 ms single half sine-wave superimposed on rated load (JEDEC method)
IFSM
75
A
Maximum Instantaneous Forward Voltage at 2.0A
VF
0.95
1.7
2.2
V
Maximum DC Reverse Current
at Rated DC Blocking Voltage
IR
5.0
20
A
Maximum Reverse Recovery Time (Note 1)
Trr
35
ns
Typical Junction Capacitance (Note 2)
CJ
50
pF
Junction Temperature Range
TJ
-65to+150
Storage Temperature Range
TSTG
-65to+150
Notes :
( 1 ) Reverse Recovery Test Conditions : IF = 0.5 A, IR = 1.0 A, Irr = 0.25 A.
( 2 ) Measured at 1.0 MHz and applied reverse voltage of 4.0 VDC
