SG3532

The SG3532 is a versatile, general-purpose voltage regulator designed as a substantially improved replacement for the popular SG723 device. The SG3532 regulators retain all the versatility of the
SG723 but have the added benefits of operation with input voltages as low as 4.5 volts and as high as 50 volts; a low noise, low voltage reference; temperature compensated, low threshold current limiting; and protective circuits which include thermal shutdown and independent current limiting of both the reference and output voltages. A separate remote shutdown terminal is included . In the dual-in-line package an open collector output is available
for low input-output differential applications.

The SG3532 is available in both hermetic 14-pin cerdip and 10-pin TO- 96 packages. In the T-package, these units are interchangeable with the LAS- 1000 and LAS-1100 regulators. The SG1532 is rated for operation over the ambient temperature range of -55 to 125 while the SG2532 and SG3532 are intended for industrial applications of 0 to 70.
