Reed Relay 1 Form A 12 V SIL
SIL12-1A72-71L: Reed Relay 1 Form A 12 V SIL
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Features: ·Low profile (4.0mm max. height) SMD type.·Magnetically shielded, suitable for high dens...
Contact Form : | 1 Form A (SPST-NO) | Coil Voltage : | 12 VDC | ||
Maximum Switched Power : | 10 W | Maximum Switched Current : | 0.5 A | ||
Coil Suppression Diode : | No | Coil Resistance : | 1000 Ohms |
Technical/Catalog Information | SIL12-1A72-71L |
Vendor | MEDER electronic |
Category | Relays |
Relay Type | Reed |
Mounting Type | Through Hole |
Termination Style | PC Pin |
Circuit | SPST-NO (1 Form A) |
Contact Rating @ Voltage | 1A @ 200VAC/DC |
Coil Voltage | 12VDC |
Control Off Voltage (Min) | 1.8 VDC |
Control On Voltage (Max) | 8.4 VDC |
Coil Current | 12mA |
Coil Type | Standard |
Lead Free Status | Lead Free |
RoHS Status | RoHS Compliant |
Other Names | SIL12 1A72 71L SIL121A7271L |
