SJ1-3525N

Series: -
Manufacturer: CUI Inc
Connector Type: Phone Jack
Gender: Female
Termination: Solder
Shielding: Unshielded
Features: -
Signal Lines: Stereo
Plug/Mating Plug Diameter: 3.50mm (0.141", 1/8", Mini Plug) - Headphone
Internal Switch(s): Two Switches
Mounting Type: Through Hole, Right Angle
Color - Contact: Silver
Number of Positions/Contacts: 3 Conductors, 5 Contacts


Pinout




Specifications




Description

The SJ1-3525N has some points of specifications such as: (1)Contact resistance: 100 m Ohms or less under all conditions, including after life testing; (2)Insulation resistance: 100 M Ohms or greater at 500 Vdc; (3)Dielectric withstand voltage: 500 Vac RMS for 1 minute; (4)Endurance: 5,000 cycles per minute; (5)Operating temperature: -25°C to 85°C. If you want to know more information such as the electrical characteristics about it, please download the datasheet in www.seekic.com or www.chinaicmart.com.



Parameters:

Technical/Catalog Information	SJ1-3525N
Vendor	CUI Inc
Category	Connectors
Connector Type	Phone Jack
Gender	Female
Plug/Mating Plug Diameter	3.50mm (0.141", 1/8", Mini Plug)
Signal Lines	Stereo
Number of Positions/Contacts	3 Conductors, 5 Contacts
Mounting Type	Through Hole, Right Angle
Features	-
Color	Black
Termination	Solder
Internal Switch(s)	Two Switches
Shielding	Unshielded
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	SJ1 3525N SJ13525N CP1 3525N ND CP13525NND CP1-3525N
