SKY65040-360LF

Series: -
Gain: 25dB
Manufacturer: Skyworks Solutions Inc
Test Frequency: 1.95GHz
Current - Supply: 100mA
Packaging: Cut Tape (CT)
RF Type: CDMA, GSM, WCDMA
Frequency: 1.5GHz ~ 2.4GHz
P1dB: 16dBm (39.8mW)
Noise Figure: 0.65dB
Voltage - Supply: 5.5 V
Package / Case: 8-TFDFN Exposed Pad


Specifications

• Ultra low noise figure: 0.65 dB @ 1.95 GHz
• Excellent input and output return loss
• Adjustable gain: 1525 dB @ 1.95 GHz
• High output 3rd order intercept: 34.5 dBm @ 65 mA
• Output P_{1 dB}: 16 dBm @ 1.95 GHz
• Single, positive DC supply voltage
• Adjustable supply current, 30100 mA
• Low cost small 8-lead QFN 2 x 2 mm package
• Available lead (Pb)-free, RoHS-compliant, and Green?, MSL-1 @ 260 °C per JEDEC J-STD-020

Description

Low Noise Amplifier 1.52.4 GHz

The SKY65040-360LF is a high performance, two-stage ultralow noise amplifier fabricated from Skyworks advanced pHEMT process and packaged in a QFN 8L 2 x 2 mm package. The device features excellent input and output return loss and an integrated interstage matching network. The SKY65040-360LF's ultralow noise figure, high gain and excellent third order intercept (IP3) allows it to be used in various receiver and transmitter applications.

The SKY65040-360LF is lead (Pb)-free and RoHS-compliant.

Parameters:

Technical/Catalog Information	SKY65040-360LF
Vendor	SKYWORKS SOLUTIONS INC (VA)
Category	RF and RFID
Package / Case	8-QFN
Voltage - Supply	5.5 V
Current - Supply	100mA
Gain	25dB
Frequency	1.5GHz ~ 2.4GHz
RF Type	CDMA, GSM, WCDMA
Packaging	Digi-Reel?
Noise Figure	0.65dB
P1db	16dBm
Test Frequency	1.95GHz
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	SKY65040 360LF SKY65040360LF 863 1066 6 ND 86310666ND 863-1066-6
