SLE66CL160S

The dual interface controller SLE 66CL160S is a member of the Infineon Technologies high-end security controller family in 0.6 µm CMOS technology. It contains a contactless and a contact-based interfaces on a single chip and supports symmetric and public-key algorithm such like DES
and Elliptic Curve.

The CPU SLE 66CL160S provides the high efficiency of the 8051 instruction set extended by additional powerful instructions with enhanced performance.

The controller SLE 66CL160S offers 31.5 Kbytes of User-ROM, 256 bytes internal RAM, 1 Kbytes XRAM and 16 Kbytes EEPROM. It suits the requirements of the new generation of operating systems.
