SLE66CX1360PE

`  8/16-bit microcomputer in 0.22 µm CMOS technology
`  Instruction set opcode compatible with standard SAB 8051 processor
`  Downward compatibility to existing SLE 66CxxxP products for existing masks
     (without using the new features)
`  Addressable memory up to 16 Mbyte
`  Additional enhanced instructions for direct physical memory access of >64kByte
`  Typically saves up to 90 % code space and increases execution speed up to 80%.
`  Dedicated, non-standard architecture with execution time 6 times faster
     than standard SAB 8051 processor at same external clock.
     (Up to 18 times faster using internal frequency PLL x 3 compared to external clock).
`  308 Kbytes User ROM for application programs
`  136 Kbytes MicroSlim-EEPROM for increased memory requirements in mobile applications
`  6 Kbytes XRAM, 256 bytes internal RAM, 700 bytes Crypto RAM.
`  Enhanced Memory Management and Protection Unit (MMU) with application
     and user defined segments
`  Dual Key Triple DES (DDES)
`  Advanced Crypto Engine:
`  Up to 1100 bit RSA calculation in Hardware
`  Up to 2048 bit RSA calculation via fast and secure RSA 2048 crypto  library
     (CC EAL 5+ certified withinSLE66CX322P, refer to product brief)
`  Supports Elliptic Curves over GF[p]
`  CC EAL5+ certification according to BSI-PP-0002 planned
`  True Random Number Generator with Firmware test function
`  CRC Module
`  16-bit Interrupt Module
`  Code executions during E²-programming for faster personalization
`  EEPROM programming voltage generated on chip
`  Internal Clock with up to 33 MHz:
     Programmable internal frequency (PLL x1, x2, x3, x4 and free running mode(s)).
`  Adjustable internal frequency according to available power or required performance
`  Increased internal frequency for maximum performance
`  Internal frequency is automatically adjusted to guarantee a given limited power  consumption
`  Two 16-bit Autoreload Timer
`  Power saving sleep mode
`  Ext. Clock freq. 1 up to 7.5 MHz
`  UART for handling serial interface in accordance with
     ISO/IEC 7816 part 3 supporting transmission protocols T=1 and T=0
`  Supply voltage range:1.8 V, 3.0 V, 5.0 V
`  Support of current consumption limits by GSM / UICC applications
      < 10 mA @  5.5 V
      <   6 mA @  3.3 V
      <   4 mA @  1.98 V
`  Operating Temperature range: -25 to +85°C
`  Storing temperature range: 40° to +125°C
`  ESD protection larger than 6 kV (HBM)

The SLE66CX1360PE is another member of the improved 66PE-series of Infineon Technologies. This high performance security crypto controller is manufactured in advanced 0.22 µm CMOS technology. It is downward compatible to existing 66P controller derivatives. The well known ECO2000 8/16 bit CPU provides the high efficiency of the SAB 8051 instruction set extended by additional powerful instructions together with enhanced performance, memory sizes and security features compared to existing 66P derivatives.
