MFG:GS Package Cooled:30000 D/C:2004
MFG: GS
Package Cooled: 30000
D/C: 2004
Description: Transil diodes provide high overvoltage protection by clamping action. Their instantaneous reponse to ...
Transil diodes provide high overvoltage protection by clamping action. Their instantaneous reponse to transients makes them praticularly suited to protect voltage sensitive devices such as MOS Technology and low voltage supplied IC's.
| Symbol | Parameter |
Value |
Unit | |
| PP | Peak pulse power dissipation See note 1 and derating curve Fig 1. |
Tamb = 25 |
400 |
W |
| P | Power dissipation on infinite heatsink See note 1 and derating curve Fig 1. |
Tlead = 50 |
5 |
W |
| IFSM | Non repetitive surge peak forward current. For unidirectional types. |
Tamb = 25 t =10 ms |
50 |
A |
| Tstg Tj |
Storage and junction temperature range |
- 65 to + 175 150 |
| |
| TL | Maximum lead temperature for soldering during 10 s. |
260 |
||
SM4T6V8
