SPP20N65C3

MOSFET COOL MOS N-CH 650V 20.7

product image

SPP20N65C3 Picture
See larger image
SeekIC No. : 00160301 Detail

SPP20N65C3: MOSFET COOL MOS N-CH 650V 20.7

SPP20N65C3 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
SPP20N65C3
Mfg:
Infineon Technologies
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/26

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Transistor Polarity : N-Channel Drain-Source Breakdown Voltage : 650 V
Gate-Source Breakdown Voltage : +/- 20 V Continuous Drain Current : 20.7 A
Resistance Drain-Source RDS (on) : 0.19 Ohms Configuration : Single
Maximum Operating Temperature : + 150 C Mounting Style : Through Hole
Package / Case : TO-220AB Packaging : Tube

Description

Transistor Polarity : N-Channel
Gate-Source Breakdown Voltage : +/- 20 V
Configuration : Single
Mounting Style : Through Hole
Drain-Source Breakdown Voltage : 650 V
Maximum Operating Temperature : + 150 C
Packaging : Tube
Package / Case : TO-220AB
Resistance Drain-Source RDS (on) : 0.19 Ohms
Continuous Drain Current : 20.7 A


Features:

• New revolutionary high voltage technology
• Worldwide best RDS(on) in TO 220
• Ultra low gate charge
• Periodic avalanche rated
• Extreme dv/dt rated
• High peak current capability
• Improved transconductance


Specifications

Parameter Symbol Value Unit
SPP_I SPA
Continuous drain current
TC = 25 °C
TC = 100 °C		 ID 20.7
13.1		 20.71)
13.11)		 A
Pulsed drain current, tp limited by Tjmax ID puls 62.1 62.1 A
Avalanche energy, single pulse
ID=3.5A, VDD=50V		 EAS 690 690 mJ
Avalanche energy, repetitive tAR limited by Tjmax2)
ID=7A, VDD=50V		 EAR 1 1
Avalanche current, repetitive tAR limited by Tjmax IAR 7 7 A
Gate source voltage VGS ±20 ±20 V
Gate source voltage AC (f >1Hz) VGS ±30 ±30
Power dissipation, TC = 25°C Ptot 208 34.5 W
Operating and storage temperature Tj , Tstg -55...+150 °C
Drain Source voltage slope
VDS = 480 V, ID = 20.7 A, Tj = 125 °C		 dv/dt 50 V/ns



Parameters:

Technical/Catalog InformationSPP20N65C3
VendorInfineon Technologies
CategoryDiscrete Semiconductor Products
Mounting TypeThrough Hole
FET PolarityN-Channel
Drain to Source Voltage (Vdss)650V
Current - Continuous Drain (Id) @ 25° C20.7A
Rds On (Max) @ Id, Vgs190 mOhm @ 13.1A, 10V
Input Capacitance (Ciss) @ Vds 2400pF @ 25V
Power - Max208W
PackagingTube
Gate Charge (Qg) @ Vgs114nC @ 10V
Package / CaseTO-220
FET FeatureStandard
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names SPP20N65C3
SPP20N65C3
SPP20N65C3IN ND
SPP20N65C3INND
SPP20N65C3IN
