ST92F120

 ` Memories
     Internal Memory: up to 128 Kbytes Single Voltage FLASH, 2 to 4 Kbytes RAM, 1K byte emulated
        EEPROM (E3PROM^TM)
    224 general purpose registers (register file) available as RAM, accumulators or index pointers

` Clock, Reset and Supply Management
    Register-oriented 8/16 bit CORE with RUN, WFI, SLOW, HALT and STOP modes
    0-24 MHz Operation (internal Clock), 4.5 - 5.5 Volt voltage range
    PLL Clock Generator (3-5 MHz crystal)
    Min. instruction time: 83 ns (24 MHz int. clock)

` Interrupt Management
    77 I/O pins
    4 external fast interrupts + 1 NMI
    Up to 16 pins programmable as wake-up or additional external interrupt with multi-level interrupt handler

` Timers
    16-bit Timer with 8 bit Prescaler, able to be used as a Watchdog Timer with a large range of service
         time (HW/SW enabling through dedicated pin)
    16-bit Standard Timer that can be used to generate a time base independent of PLL Clock Generator
    Two 16-bit independent Extended Function Timers (EFTs) with Prescaler, 2 Input Captures and two
        Output Compares
    Two 16-bit Multifunction Timers, with Prescaler, 2 Input Captures and 2 Output Compares

` Communication Interfaces
    2 Serial Communication Interfaces with asynchronous and synchronous capabilities. Software Management
        and synchronous mode supported
    Serial Peripheral Interface (SPI) with Selectable Master/Slave mode
    J1850 Byte Level Protocol Decoder (JBLPD) (on J versions only)
    Full I²C multiple Master/Slave Interface supporting Access Bus

` 8-bit Analog to Digital Converter allowing up to 16 input channels
` DMA Controller for reduced processor overhead
` Instruction Set
     Rich Instruction Set with 14 Addressing Modes
    Division-by-zero trap generation
` Development Tools
    Versatile Development Tools, including Assembler, Linker, C-Compiler, Archiver,  Source Level
        Debugger, Hardware Emulators and Real Time Operating System

Note:
Stresses above those listed as "absolute maximum ratings" may cause permanent damage to the device. This is  a stress rating only and functional operation of the device at these conditions is not implied. Exposure to maximum rating conditions for extended periods may affect device reliability. All voltages are referenced to VSS=0.

The ST92F120 microcontroller is developed and manufactured by STMicroelectronics using a proprietary n-well HCMOS process. Its performance derives from the use of a flexible 256-register programming model for ultra-fast context switching and real-time event response. The intelligent onchip peripherals offload the ST92F120 core from I/O and data management processing tasks allowing critical application tasks to get the maximum use of core resources. The new-generation ST92F120 MCU devices now also support low power consumption and low voltage operation for power-efficient and low-cost embedded systems.
