TL751L

The TL750L and TL751L series of fixed-output voltage regulators offer 5-V, 8-V, 10-V, and 12-V options. TheTL751L series also has an enable (ENABLE ) input. When ENABLE is high, the regulator output is placed in thehigh-impedance state. This gives the designer complete control over power up, power down, or emergencyshutdown.

The TL750L and TL751L series are low-dropout positive-voltage regulators specifically designed forbattery-powered systems. These devices incorporate overvoltage and current-limiting protection circuitry, alongwith internal reverse-battery protection circuitry to protect the devices and the regulated system. The series isfully protected against 60-V load-dump and reverse-battery conditions. Extremely low quiescent current duringfull-load conditions makes these devices ideal for standby power systems.
