Part Number: TMC1103
Description: Incorporated into the TMC1103 are three analog-to-digital (A/D) converters, each with an independent c...
- Table of contents:
TMC1103
-
Suppliers
DataSheet
General Description
TMC1103 General Description
Incorporated into the TMC1103 are three analog-to-digital (A/D) converters, each with an independent clock, reference voltage and input clamp. Analog ignals are converted to Triple 8-bit digital words at sample rates up to 50 Msps (Megasamples per second) per channel.
Integral Track/Hold circuits deliver excellent performance on signals with full-scale spectral components up to 12 MHz. Innovative two-step conversion architecture and submicron CMOS technology reduce typical power dissipa-tion to 100 mW per converter.
Power is derived from a single +5 Volt power supply. Out-puts are three-state outputs and TTL/CMOS-compatible.
TMC1103 package is a 80-lead Metric Quad Flat Pack (MQFP). Performance specifications are guaranteed from 0°C to 70°C.
TMC1103 Maximum Ratings
| Parameter |
Condition |
Min |
Typ |
Max |
Unit |
| Power Supply Voltages | |||||
| VDDA |
Measured to AGND |
-0.5 |
+7.0 |
V | |
| VDD |
Measured to DGND |
-0.5 |
+7.0 |
V | |
| VDDA |
Measured to VDD |
-0.5 |
+0.5 |
V | |
| AGND |
Measured to DGND |
-0.5 |
+0.5 |
V | |
| Digital Inputs | |||||
| Applied Voltage |
Measured to DGND |
-0.5 |
VDD +0.5 |
V | |
| Forced current |
-10.0 |
+10.0 |
mA | ||
| Analog Inputs | |||||
| Applied Voltage |
Measured to AGND |
-0.5 |
VDD +0.5 |
V | |
| Forced current |
-10.0 |
+10.0 |
mA | ||
| Digital Outputs | |||||
| Applied voltage |
Measured to DGND |
-0.5 |
VDD + 0.5 |
V | |
| Forced current |
-6.0 |
+6.0 |
mA | ||
| Short circuit duration |
Single output in HIGH state to ground) |
1 second |
|||
| Temperature | |||||
| Operating, ambient |
-20 |
110 |
°C | ||
| Junction |
+150 |
°C | |||
| Lead, soldering |
10 seconds |
+300 |
°C | ||
| Vapor Phase soldering |
1 minute |
+220 |
°C | ||
| Storage |
-65 |
+150 |
°C | ||
| Electrostatic Discharge |
EIAJ test method |
±150 |
V | ||
TMC1103 Features
• 8-bit resolution
• 50 Msps conversion rate
• Low power: 100mW per channel @ 20 Msps
• Integral track/hold
• Independent Input Clamps
• Independent clock inputs
• Integral and differential linearity error 0.5 LSB
• Differential phase 0.7 degree
• Differential gain 1.8%
• Single +5V power supply
• Three-state TTL/CMOS-compatible outputs
• Low cost
• 50 Msps conversion rate
• Low power: 100mW per channel @ 20 Msps
• Integral track/hold
• Independent Input Clamps
• Independent clock inputs
• Integral and differential linearity error 0.5 LSB
• Differential phase 0.7 degree
• Differential gain 1.8%
• Single +5V power supply
• Three-state TTL/CMOS-compatible outputs
• Low cost
TMC1103 Typical Application
• Video digitizing (composite and Y-C)
• VGA and CCD digitizing
• LCD projection panels
• Image scanners
• Personal computer video boards
• Multimedia systems
• Low cost, high speed data conversion
• VGA and CCD digitizing
• LCD projection panels
• Image scanners
• Personal computer video boards
• Multimedia systems
• Low cost, high speed data conversion
TMC1103 Connection Diagram
