V62C1161024L

Features: • Ultra Low-power consumption - Active: 30mA ICC at 70ns - Stand-by: 5 A(CMOS input/output) 1 A(CMOS input/output,Lversion)• 70/85/100/120 ns access time• Equal access and cycle time• Single +1.8V to 2.2V Power Supply• Tri-state output• Automatic power...

product image

V62C1161024L Picture
See larger image
SeekIC No. : 004540195 Detail

V62C1161024L: Features: • Ultra Low-power consumption - Active: 30mA ICC at 70ns - Stand-by: 5 A(CMOS input/output) 1 A(CMOS input/output,Lversion)• 70/85/100/120 ns access time• Equal access an...

V62C1161024L Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
V62C1161024L
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/26

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• Ultra Low-power consumption
   - Active: 30mA ICC at 70ns
   - Stand-by: 5 A(CMOS input/output)
                      1 A(CMOS input/output,Lversion)
• 70/85/100/120 ns access time
• Equal access and cycle time
• Single +1.8V to 2.2V Power Supply
• Tri-state output
• Automatic power-down when deselected
• Multiple center power and ground pins for improved noise immunity
• Individual byte controls for both Read and Write cycles
• Available in 44 pin TSOP (II) Package


Pinout

Connection Diagram


Specifications

Parameter Symbol Minimum Maximum Unit
Voltage on Any Pin Relative to Gnd Vt -0.5 +4.0 V
Power Dissipation PT - 1.0 W
Storage Temperature (Plastic) Tstg -55 +150
Temperature Under Bias Tbias -40 +85

* Note: Stresses greater than those listed above Absolute Maximum Ratings may cause permanent damage to the device. This is a stress rating only and function operation of the device at these or any other conditions outside those indicated in the operational sections of this specification is not implied. Exposure to Absolute Maximum Rating conditions for extended periods may affect reliability.


Description

The V62C1161024L is a Low Power CMOS Static RAM organized as 65,536 words by 16 bits. Easy memory expansion is provided by an active LOW (CE) and (OE) pin.

This device has an automatic power-down mode feature when deselected. Separate Byte Enable controls (BLE and BHE) allow individual bytes to be accessed. BLE controls the lower bits I/O1 - I/O8. BHE controls the upper bits I/O9 - I/O16.

Writing to these devices is performed by taking Chip Enable (CE) with Write Enable (WE) and Byte Enable (BLE/BHE) LOW.

Reading from the device is performed by taking Chip Enable (CE) with Output Enable (OE) and Byte Enable (BLE/BHE) LOW while Write Enable (WE) is held HIGH.
