VHZ555

Features: • VH102Z Series Nominal Temperature Coefficient of Resistance: ± 0.2ppm/ MIL Range (see table 2)• VHZ555 Temperature Coefficient of Resistance: ± 2ppm/ ( 55to + 125);• Selected TCR Tracking: to 0.5ppm/ (matched sets)• Load-Life Stability: ± 0.0025% maximum ∆...

product image

VHZ555 Picture
See larger image
SeekIC No. : 004541466 Detail

VHZ555: Features: • VH102Z Series Nominal Temperature Coefficient of Resistance: ± 0.2ppm/ MIL Range (see table 2)• VHZ555 Temperature Coefficient of Resistance: ± 2ppm/ ( 55to + 125);• Se...

VHZ555 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
VHZ555
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/28

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• VH102Z Series Nominal Temperature Coefficient of Resistance: ± 0.2ppm/ MIL Range (see table 2)
• VHZ555 Temperature Coefficient of Resistance: ± 2ppm/ ( 55to + 125);
• Selected TCR Tracking: to 0.5ppm/ (matched sets)
• Load-Life Stability: ± 0.0025% maximum ∆R at 0.1 watt, + 60, 2,000 hours (VHZ555)
• Power Rating: 0.6 Watts at + 70; 0.3 Watts at + 125
• Resistance Tolerance (Initial Resistance Accuracy): ± 0.005% tightest to ± 1.0% loosest
• Resistance Range:
   VH102Z: 100R to 100K
   VHZ555: 4R99 to 121K



Description

The VHZ series of resistors is the hermetic version of the molded "Z" series devices. Hermetic sealing eliminatesthe ingress of both oxygen, which degrades resistors over long periods, and moisture which degrades resistors more quickly. These VHZ series parts are made with glass to metal seal enclosures employing Kovar eyelets which allow the copper leads to pass through the enclosure to minimize the thermal EMF from the lead junctions. Rubber fill between the metal housing and resistance element acts both as a mechanical damper and thermal transfer path.

In the VHZ series , VH102Z is the hermetically-sealed counterpart of the Z201 high-performance molded resistors. VHZ555 is the hermetically-sealed version of the Z555, MIL style RNC90Z.
