BSO615N, BSO615NV, BSO742RI

Table of contents:
Info of BSO615N
Info of BSO615NV
Info of BSO742RI

BSO615N, BSO615NV, BSO742RI Selling Leads, Datasheet

MFG:Infineon Technologies (VA) Category:Discrete Semiconductor Products Package Cooled:SOP8 D/C:08.09+

BSO615N, BSO615NV, BSO742RI Datasheet download

Five Points

Part Number: BSO615NV

Category: Discrete Semiconductor Products

MFG: Infineon Technologies (VA)

Package Cooled: SOP8

D/C: 08.09+

Description: MOSFET DUAL N-CH 60V 3.1A 8-SOIC

Attentive hint

Want to post a buying lead? If you are not a member yet, please select the specific/related part number first and then fill the quantity and your contact details in the "Request for Quotation Form" on the left, and then click "Send RFQ".Your buying lead can then be posted, and the reliable suppliers will quote via our online message system or other channels soon.

How to buy ?

How long will receive a response.

Top Sellers:

TOP

BSO615N Maximum Ratings

Parameter	Symbol	Values	Unit
Continuous drain current T_A = 25 °C T_A = 70 °C	L_D	2.6	A
Pulsed drain current, one channel active T_A= 25 °C	L_Dpulse	10.4	A
Avalanche energy, single pulse I_D = 3.1 A , V_DD = 25 V, R_GS= 25 I_D = -2 A , V_DD = -25 V, R_GS = 25	E_AS	60	mJ
Avalanche current,periodic limited by T_jmax	I_AR	2.6	A
Avalanche energy, periodic limited by T _jmax	E _AR	0.18	mJ
Reverse diode dv/dt I_S = 3.1 A, V_DS = 48 V, di/dt = 200 A/s, I_S = -2 A, V_DS = -48 T _jmax = 150 °C	dv/dt	6	kV/s
Gate source voltage	V_GS	±20	V
Power dissipation, one channel active T_A= 25 °C	P_tot	2	W
Operating temperature	T _j , T _stg	-55 ... +150	°C
IEC climatic category, DIN IEC 68-1		55/150/56	°C

BSO615N Features

· Dual N Channel
· Enhancement mode
· Avalanche rated
· Logic Level
· dv/dt rated

BSO615NV Parameters

Technical/Catalog Information	BSO615NV
Vendor	Infineon Technologies (VA)
Category	Discrete Semiconductor Products
Mounting Type	Surface Mount
FET Polarity	2 N-Channel (Dual)
Drain to Source Voltage (Vdss)	60V
Current - Continuous Drain (Id) @ 25° C	3.1A
Rds On (Max) @ Id, Vgs	120 mOhm @ 3.1A, 10V
Input Capacitance (Ciss) @ Vds	340pF @ 25V
Power - Max	2W
Packaging	Cut Tape (CT)
Gate Charge (Qg) @ Vgs	12nC @ 10V
Package / Case	SO-8
FET Feature	Logic Level Gate
Lead Free Status	Contains Lead
RoHS Status	RoHS Non-Compliant
Other Names	BSO615NV BSO615NV BSO615NVINCT ND BSO615NVINCTND BSO615NVINCT
